Expert printing made easy

Roll to Roll LED-UV inkjet printer

MORE “PLUS” VALUE

Having won the “Best Roll-to-Roll Printer Less Than 170cm” award from the European Digital Press (EDP) Association, 2024, the new and highly competitive UJV100-160Plus UV printer is an absolute game changer.

Inheriting the strong features of the UJV100-160, this Plus model comes with three additional functions to not only expand the range of applications, but also reduce running costs and improve work efficiency.
Expand your applications with the new pull-back printing feature, which enables three-layer printing with combinations of white, colour and/or clear ink. With Rasterlink7’s new ink saving feature, you can easily reduce ink consumption while maintaining color tones. And in combination with the CG-AR Cutter, you can now cut directly from Rasterlink7 to the cutter without using FineCut.
...

Unique features

...
  • Pull-Back Printing...
    expands the range of multi-layer applications.

    The pull-back printing feature expands the variety of multi-layer applications, allowing up to 3-layer printing with clear and white ink, while being less dependent on the installed ink configuration.
...
  • Ink Saving Technology...
    that lowers ink consumption while maintaining colour tones.
    A free of charge function available in RasterLink7, allows the user to easily reduce ink consumption to approximately 50%, while maintaining the colour tones of your image.
...
  • Seamless linkage...
    for a Print & Cut solution
    By combining the UJV100-160Plus with a CG-AR cutting plotter, operations are simplified, allowing cut data to be sent directly from Rasterlink7 without the need for design software.
...
  • Sustainable and Eco-friendly Technology...
    with UV-LED light source and Greenguard Gold-certified UV-curable inks.
    The UJV100-160Plus is equipped with a UV-LED light source, which reduces electricity costs as it relies on less power. With a maximum power consumption of 0.5kW, which is 20% less than the power consumption of latex or eco-solvent printers, it reduces both energy costs and CO2 emissions.

    The printer is also environmentally friendly as it uses only Greenguard Gold-certified UV-curable inks that produce almost no harmful VOCs.
...
  • DAS system...
    performs both a bi-directional and media feed adjustment.
    Mimaki’s easy-to-operate Dot Adjustment System (DAS) automatically performs two adjustments: the bi-directional adjustment and the media feed adjustment.
UJV100-160Plus
The new pull-back printing function
UJV100-160Plus
UJV100-160Plus
Seamless linkage
UJV100-160Plus
Sustainable and Eco-friendly Technology

LED-UV ink technology

renowned for low energy consumption

With a maximum power consumption of 0.5kW, less than 20% of the power consumption of latex or eco-solvent printers, UV-LED inks help to reduce energy costs and CO2 emissions.

And with the more budget-friendly LUS-190/210*, available in CMYK, white and clear, the range of applications has been further extended.

*LUS-190 is available within the EU. LUS-210 is available outside the EU.

led-uv ink UJV100-160 UV printer
Green guard UJV100-160 UV printer

For even more confidence

our products are GREENGUARD GOLD certified

GREENGUARD GOLD certified products meet the rigorous standards for low emission of volatile organic compounds (VOCs) and ensures that a product is acceptable for use in environments such as schools and healthcare facilities without polluting the indoor air quality.

This printer includes Mimaki Core Technologies that offer the best print quality, maximum productivity and reduced exposure to risks that can delay production. See below list of core technologies that are included in the UJV100-160Plus.

infinity

For continued productivity

For quality printing

What our customers say…

When ordering food at a restaurant, you would never order something you know you wouldn’t eat. Then why should buying a digital printer be any different? That’s why we chose the UJV100-160 – it has exactly the features we need – UV-LED technology, blazing fast print speeds and a very low investment cost, all without increasing the purchase price by adding features we know we’ll never use. Our printer has been running nearly 24/7 from day one and we’ve not regretted our purchase for a second!
Jacques Lombard, Wall Design, Johannesburg

ModelUJV100-160Plus
Print headOn-demand piezo head (2 staggered layout)
Print resolution360 dpi, 720 dpi, 900 dpi, 1200 dpi
Ink Type/ ColorUV-curable ink LUS-190 (C, M, Y, K, W, Cl)
UV-curable ink LUS-210 (C, M, Y, K, W, Cl)
*Availability varies depending on the regions
Ink Capacity1L bottle
Max printing width1,610 mm (63.4 in)
Max media width1,620 mm (63.8 in)
Media thickness1.0 mm or lower
Roll diameterφ250 mm or less
Roll weight45 kg or less
Roll inside diameter2 inch / 3 inch
CertificationsVCCI class A, FCC class A, ETL IEC 62368-1,
CE Marking (EMC, Low voltage, Machinery directive, and RoHS),
CB, REACH, ENERGY STAR®, EAC, RCM
InterfaceUSB2.0 Hi-Speed, Ethernet 1000 BASE-T
Power supplySingle-phase AC100-120V±10%/12A, AC200-240V±10%/8A, 50/60Hz±1Hz
Power consumptionMaximum 500W (operating), 4.5W (sleep)
Operational environmentTemperature: 20–30 °C (68–86 °F)
Humidity: 35–65% Rh (Non condensing)
Dimensions (WxDxH)2,775 x 700 x 1,475 mm (109.3 x 27.6 x 58.1 in)
Weight167 kg (368.2 lb)

Software RIP

Mimaki’s dedicated software RIP, comes in the box. Rasterlink7 is equipped with more useful and advanced functions.

software-download
Rasterlink7
Software RIP combining usability and high performance.

Cloud based monitoring tool

Mimaki Cloud Technology PICT is a cloud-based printer status monitoring tool, allowing you to easily monitor your printer from your a PC or mobile device remotely.

cloud
PICT
Mimaki Cloud Technology for remote monitoring.

Remote printer status

Mimaki Remote Access (MRA) is a remote access tool that enables you to obtain information and operate the panel of Mimaki printers and plotters from a smart device.

cloud
MRA
Mimaki Remote Access for remote operation.

LUS-190

LED-UV ink

Flexible ink with good adhesion and scratch resistance. GREENGUARD Gold certified. Available only in the EU region.

packaging
Packaging
1 litre bottle
colour
Colour
4 colours: CMYK
5 colours: CMYK W
6 colours: CMYK W Cl
ink-type
Ink type
Flexible ink with good adhesion and scratch resistance with a wide colour gamut.

LUS-210

LED-UV ink

Flexible ink with good adhesion and scratch resistance. GREENGUARD Gold certified. Available only in the non-EU region.

packaging
Packaging
1 litre bottle
colour
Colour
4 colours: CMYK
5 colours: CMYK W
6 colours: CMYK W Cl
ink-type
Ink type
Flexible ink with good adhesion and scratch resistance with a wide colour gamut.
