MAXIMISE YOUR PRODUCTIVITY…
…WITH THE ALL NEW JFX600 SERIES INDUSTRIAL FORMAT FLATBED LED-UV PRINTERS
Maximise your productivity with industry leading technology
Experience the eye-catching quality and the versatility of substrates to print on. With multiple ink options to choose from, the list of applications is virtually endless. Additionally, Mimaki’s reliable 7th generation LED-UV technology ensures quick turnaround times for all your orders.
Available in two sizes, the JFX600-2513 features a table size of 2500x1300mm, while the JFX600-2531 offers an increased print area of 2500x3100mm, opening up possibilities to more large-sized applications, such as in architecture.
Unique features
- Industry-led productivity
at more than three times faster than its predecessor, the JFX600 positions itself at the top of the IP flatbed market.Utilising 16 industrial build print heads, print speeds of up to 200 m2/h can be achieved, which is over 300% faster than its predecessor.
Supported with Mimaki’s Nozzle Check Unit (NCU) and Nozzle Recovery System (NRS), downtime is reduced to an absolute minimum and productivity is guaranteed.
- Multiple print headsto achieve ultimate speed and high colour definition.The JFX600 includes 16 industrial-built print heads to achieve ultimate speed in 4-colour configuration, or 7-colour configuration for high definition.
While the number of print heads in the printer helps it to achieve ultimate print speeds, the print head’s piezo technology makes it durable.
Variable dot technology ensures a high print quality with excellent gradients.
- IoT ready enabling easy integration of automated, un-attended production using robots.The high and stable productivity makes the JFX600 ideal for integrating with automated workflows for unattended printing.
By supporting MDL commands, which comply with Industry 4.0 requirements, the operation can be fully automated and integrated in a production line with other 3rd party peripherals.
- Ease of operationwith touchscreen on our new MPC (Mimaki Print Controller).Mimaki Printer Controller is the “on-board” PC which combines machine setup, printer operation and job control via a large user-friendly touch panel.
With Mimaki Printer Controller you can see the condition of the printer, all printer settings and control print jobs.
JFX600-2531 – Exclusive features for enhanced efficiency
Toggle Print
The Toggle Print function divides the print area into two zones: the front and the back. This feature greatly increases production efficiency by allowing users to load new media on one side while printing continues on the other. By minimising stand-by time, it optimises workflow. The maximum print size for front/rear printing in toggle print mode is 2500x1300mm.
9 Adjustable Vacuum Zones
The flatbed features 9 adjustable vacuum zones to securely hold media in place. You can customise the suction based on media size by opening or closing the valves. For improved vacuum efficiency, users can close valves or cover suction holes in unused areas. Vacuum power can be conveniently controlled with a foot pedal.
Designed to produce a wide range
of materials and applications
Versatility in inks
thanks to LED-UV ink technology
With a variety of LED-UV inks available for the JFX600 Series, the range of applications seems endless. Choose between hard inks for rigid materials, flexible inks for a variety of media, or stretchable inks for soft materials.
JFX600 Series inks have been on the market for many years and have a proven track record of quality and reliability.
For even more confidence
our products are GREENGUARD GOLD certified
GREENGUARD GOLD certified products meet the rigorous standards for low emission of volatile organic compounds (VOCs) and ensures that a product is acceptable for use in environments such as schools and healthcare facilities without polluting the indoor air quality.
JFX600 Series
Core Technologies
This printer includes Mimaki Core Technologies that offer the best print quality, maximum productivity and reduced exposure to risks that can delay production. See below list of core technologies that are included in the JFX600 Series.
For continued productivity
- Nozzle Check Unit (NCU), to detect missing nozzles
- Nozzle Recovery System (NRS), to replace missing nozzles
- Automatic Cleaning Function, to keep the print head clean
- Automatic Wiper Cleaner, to keep the wiper clean
- Mimaki Circulation Technology (MCT), preventing ink sedimentation
- Mimaki Printer Controller (MPC), on-board user interface
For quality printing
- Mimaki Advanced Pass System (MAPS4), to reduce banding
- Waveform Control (WFC), for best possible image sharpness
- Variable Dots Technology (VDT), for smoother gradations
- Mimaki Fine Diffusion (MFD), for smoother colours
- Mimaki Clear Control (MCC), for a glossy finish
| Item | JFX600-2513 | JFX600-2531 | |
| Print head | Type | On-demand piezo head | |
| Specifications | 16 heads (320 nozzles × 4 rows) (4 staggered, 4 in-line array) | ||
| Resolution | Y: 600 dpi, 1.200 dpi X: 600 dpi, 1.200 dpi | ||
| Ink set | 4-colour | C, M, Y, K | |
| 4-colour + 4-special | C, M, Y, K, W, Cl, Pr*1 | ||
| 6-colour + White | C, M, Y, K, Lc, Lm, W | ||
| Ink type | LH-100: CMYK/ CMYK WW Cl Pr*1 / CMYK LcLm WW LUS-120/LUS-150: CMYK / CMYK WW Cl Pr*1 / CMYK LcLm WW LUS-211: CMYK WW ClCl*2*3 | ||
| Media | Max. printing width | 2,500mm | |
| Maximum width | 1,300mm | 3,100mm | |
| Thickness | Up to 60mm | ||
| Weight | Up to 50kg/m2 | ||
| Distance accuracy | Absolute accuracy | ±0.3mm or ±0.3% of specified distance, whichever is greater | |
| Repeatability | ±0.2mm or ±0.1% of specified distance, whichever is greater | ||
| Perpendicularity | ±0.5mm / 500mm | ||
| Printing gap | 1.5 to 3.0mm (media thickness detected automatically) | 1.5mm (media thickness detected automatically) | |
| Ink supply | Ink bottle | ||
| Waste ink tank | Bottle type (2,600ml) | ||
| Vacuum | 2 sections, divided in X direction | 9 sections | |
| UV unit | Water-cooled UV-LED emitters x 2 | ||
| Interface | Data transfer function | 10GBASE-T Ethernet | |
| Commands | MRL-V | ||
| Noise levels | Standby | 55 dB (A) or less | |
| In operation (continuous) | 70 dB (A) or less | ||
| Power supply specifications | Single-phase 200 to 240 V AC ±10% / 24A x3; 50/60 Hz ±1 Hz | ||
| Power consumption | 4.8kW x 3 or less | ||
| External dimensions (WxDxH) | 5,270mm x 2,800mm x 1,600mm | 5,400mm x 4,850mm x 1,700mm | |
| Body Weight | 1,100kg | 1,600kg | |
| Compliance with standards | UL 775 compliant, CE marking (EMC Directive, Machinery Directive), RoHS, REACH, EAC Mark | UL62368/VCCI/FCC; CE marking (EMC Directive, Machinery Directive); RoHS, REACH | |
*2 Stretchability of each stretchable ink may vary depending on materials, please test on actual materials in advance.
*3 LUS-211 ink is available in some regions.
Software RIP
The primary task of RIP (Raster Image Processor) software is to convert the different formats of the file to be printed into data that the printer “understands” as raster data.
RasterLink7
LH-100
LED UV ink
Hard ink for rigid materials
Packaging
Colour
Ink type
LUS-120
LED UV ink
Flexible ink for rigid materials and a variety of media
Packaging
Colour
Ink type
LUS-150
LED UV ink
Flexible ink for a variety of media
Packaging
Colour
Ink type
LUS-211*
LED UV ink
Flexible ink for a variety of media
Packaging
Colour
Ink type
*LUS-211 ink available in certain areas
