Give your creativity a glow up

With the all new TS330-1600 high-volume dye sublimation printer

High quality 1.6m dye sublimation inkjet printer

The TS330-1600 is a dye sublimation inkjet printer achieving superb productivity and high image quality through Mimaki printing technology. Designed on a new platform, the printer incorporates improved conveyance mechanism and renewed usability, enabling stable and constant high-quality printing.
...

Unique features

...
  • Next level image quality ...
    A higher image sharpness with more uniform density, while reducing banding even at low pass printing.
    Image sharpness has been strongly increased due to a much higher ink droplet accuracy.

    With new high-precision print heads that offer an increased dot density (6400 nozzles), high quality at low passes is achieved.

    In addition, new imaging technology (MWDT) minimise the effect of individual head imperfections and adjustment errors while increasing the image smoothness.
...
  • Stable operation...
    Throughput is increased while operator mistakes are reduced thanks to new and improved functionalities.
    Introducing an improved conveyance control using a dual-engine take-up unit, media edge guides, V-shaped cut function and a new post heater, stable paper transport is guaranteed.

    While the new cloth wiper, designed to soak ink and reduce ink splattering during the cleaning cycle, further enhance the stability of the TS330-1600.
...
  • Versatile applications...
    With the variety of inks colours, including fluorescent colours, the range of vivid and eye-catching applications seems endless.
    With a proven track record for Mimaki’s Sb411 high quality sublimation transfer ink, including light and fluorescent colours, the creative possibilities for producing home interiors, sportswear and fashion apparel applications have never been so exciting.
...
  • Scalable production...
    With the optional mini jumbo roll unit and the 10KG ink supply unit, you can scale up your production.
    With approximately 2,500 linear metres of transfer paper available, productivity can be maximised, while reducing running costs.
ts330-1600 sunglasses
Versatile applications
ts330-1600 solvent printer fabric wiper jv3060
Fabric wiper
mimaki technologies
Mimaki Weaving Dot Technology
ts330-1600
Stable operation
ts330-1600 roller
Mini jumbo roll unit
ts300-1600 ink tank
10kg ink tank

Dye sublimation inks

for vibrant colours and durability

The TS330-1600 comes with Mimaki’s high quality Sb411 dye sublimation ink which is known for its rub fastness, durability and colour intensity.

Available in a 4, 6 or even 7 colour configuration, supporting light colours and fluorescent colours contributes to the range of applications.

Sb411 comes in 2 litre ink packages or high capacity 10kg ink tanks.

ts330-1600 drops
ts330-1600 inks

For even more confidence

our inks are OEKO-TEX® certified

Mimaki inks Sb411 are OEKO-TEX® certified. ECO PASSPORT by OEKO-TEX® is a mechanism by which textile chemical suppliers demonstrate that their products are suitable to print skin-friendly clothing and other textiles for end users.
This certificate therefore constitutes an important decision-making element when purchasing inks for textile production.

This printer includes Mimaki Core Technologies that offer the best print quality, maximum productivity and reduced exposure to risks that can delay production. See below list of core technologies that are included in the TS330-1600.

For continued productivity

For quality printing

ModelTS330-1600
Print head2 drop-on-demand piezoelectric head; stagger arrangement
Print resolutionY: 300, 600dpi
X: 600dpi, 900 dpi, 1200
Drop sizeMin: 4pl
Head heightManual adjustment (3.0/3.5/4.0 mm from platen)
Compatible inksSb411: BMYK / 4C+F: BMYK FyFp* / 6C: BMYKLbLm / 6C+F: BMYKLbLm FyFp* / 7C: BMYKLkLbLm
Ink supply2000ml Ink bag
Optional 10kg Tank (BMYK only)
Max printing width1,610mm
Max media width1,620mm
Media thickness1.0mm or less
Outside diameter250mm or less
Inner diameter2-inch / 3-inch
Roll weight45kg or less
InterfaceUSB2.0 / Ethernet 1000 BASE-T
Body weight241kg
Dimension (WxDxH)3,170mm / 1,215mm / 1,305mm
Power supply1 x Single phase (AC100~120/200~240V +/- 10%, 50/60Hz +/- 1Hz)
Power consumptionMax: 1.44kW or less
Safety StandardsIEC 62368-1 compliant ETLCB, CE (EMC Directive, Low Voltage Directive, Machinery Directive, RoHS Directive) REACH, VCCI Class A, FCC Class AEAC, KC, RCM, UKCA, EnergyStar
*FyFp are Sb410

Software RIP

The primary task of RIP (Raster Image Processor) software is to convert the different formats of the file to be printed into data that the printer “understands” as raster data.

software
TxLink 4 lite
This dedicated textile RIP software has additional features for textile applications such as “step and repeat” and nesting.

SB411

Dye Sublimation ink

Mimaki ink developed for fast printing on transfer paper

packaging
Packaging
2 liter ink Package (all colours)
10KG ink tank (Bl M Y K only)
colour
Colour
4 colours: Bl M Y K
6 colours : Bl M Y K Lb Lm
7 colours : Bl M Y K Lb Lm Lk
ink-type
Ink type
Sublimation ink with very good rub fastness, durability and colour intensity.

SB410

Fluorescent Pink & Yellow inks

Mimaki ink developed for fast printing on transfer paper

packaging
Packaging
2 liter ink Package (all colours)
10KG ink tank (Bl M Y K only)
colour
Colour
4 colours + Fluorescent: Bl M Y K Fp Fy
6 colours + Fluorescent:  Bl M Y K Lb Lm Fp Fy
ink-type
Ink type
Fluorescent ink with very good rub fastness, durability and colour intensity.
