A new generation high-speed dye sublimation textile printer

Developed specifically for the textile print industry, the revolutionary new Mimaki TS300P-1800 delivers cost effective dye sublimation printing while maintaining high quality and high productivity. Perfectly suited to the creation of fashion, apparel, sportswear, furnishings and PoS, the TS300P-1800 uses state-of-the-art technology to set new performance benchmarks for the sector.

High print speeds
Specially designed for flimsy media
Cost effective ink
  • Maximum print speed of 115m2/h (360 x 360dpi, 1 pass, Bi)
  • New Sb410 high performance, affordable sublimation transfer ink
  • Mimaki MBIS3 Bulk Ink System for long-run continuous printing
  • Latest Mimaki MAPS4 Advanced Pass System
  • Nozzle Check Unit (NCU) ensures reliable continuous print operation
  • Cockling reduction transfer mechanism for higher quality print


Fashion and Apparel, Sportswear, Home Furnishing and Upholstery Fabrics, Soft signage, Textile retail, PoS, Exhibition Graphics, Wall art and Much more…

Specifications of TS300P-1800

Printhead On-demand piezo head (4 in-line printheads)
Print resolution 360dpi, 540dpi, 720 dpi, 1080 dpi
Maximum print width 1,940 mm (76.4 in)
Maximum media width 1,950 mm (76.8 in)
Ink Type/Color Sb410(Bl,M,Y,K,Lbl,Lm)
Package size 2L Ink pack
Media thickness 1.0 mm or less
Rolled media weight 40 kg (88 lb) or less
Certifications VCCI class A, FCC class A, ETL UL 60950-1CE Marking (EMC, Low voltage, Machinery directive, and RoHS),
CB, REACH, Energy Star, CCC, RCM
Interface USB 2.0 Hi-speed / Ethernet 1000BASE-T
Power supply Single-phase AC100 ­­­– 120V / AC200 – 240V
Power consumption (AC100V)1.44kW / (AC200V)1.92kW
Operational environment Temperature: 20 – 30 °C ( 68 – 86 °F )Humidity: 35 – 65% Rh (Non condensing)
Dimensions (W × D × H) 3,200 × 850 × 1,857 mm (126 x 33.4 x 73 in )
Weight 213 kg (469.6 lb)

All TS300P-1800 inks are ECO PASSPORT by OEKO-TEX® certified.

Features of TS300P-1800

Maximum print speed of 115m2/h for high productivity

The TS300P-1800 optimizes the printing speed and quality to produce the desired print results. For this purpose, it provides a wide range of printing modes, from the draft printing mode (which operates at the maximum speed of 115m2/h) to high-quality printing mode
Speed TS1800P-1800

‘Cockling’ reduction features

TS300P-1800 incorporates a number of innovative new features to reduce the effects of ‘cockling’ (the wrinkling of the media surface due to high levels of ink absorbtion, which is particularly prevalent where low-cost or thin transfer papers are being used).
ts300P-1800 cockling

  1. High-gap print head with high accuracy ink drop placement ensures clear, sharp print
  2. Vacuum media hold-down system, smooths out cockling effects by using vacuum suction beneath the platen
  3. Larger media press plates reduce media uplift immediately after printing
  4. Auto Media Feeder (AMF) maintains stable media feeding and take up by automatically applying the correct tension


New Sb410 High Performance Ink Sets

SB410The new Sb410 Ink sets offer a number of additional benefits over the conventional Sb53 inks, including;

  • Reduced cost significantly improves profitability
  • Improved ink resolvability and stability ensures better ink flow and jetting with easier and less frequent cleaning of nozzles required
  • Low-sedimentation formulation delivers beautiful, vibrant, high-density printing
  • Low smoke emission is beneficial for the work environment and improves production efficiency
  • Mimaki Bulk Ink System 3 (MBIS3) utilises large 2 litre ink packs to deliver profitable long-run continuous print


MAPS4 Advanced Pass System

MAPS is Mimaki’s unique anti-banding feature. To prevent banding, swath boundaries are overprinted and boundaries prone to banding are printed with fewer ink droplets.
mimaki maps 4

Continuous Uninterrupted Printing Features

continuous-uninterrupted-printing-featuresNozzle Recovery Function
In the event of a nozzle malfunction not being repairable by the use of the maintenance function, printing can continue by the use of another nozzle, without any loss of productivity
or a reduction in image quality.
Uninterrupted Ink Supply System (UISS)
Two ink packs per colour can be set with the UISS function. When an ink bottle runs out, another bottle of the same colour automatically starts supplying ink.

Sophisticated RIP software maximizes the performance of TS300P-1800

A choice of RIP software is included:

rasterlink 6Userfriendly RIP Rasterlink 6

  • More beautiful and advanced print results are achieved by following a user-friendly interface that is easy to operate
  • Colour replacement function enhances the ability to re-create printed images
  • Print colour can be simulated on Illustrator / Photoshop without an actual print *This function requires MPM2 (Mimaki Profi le Master 2)
  • Program update and profi le download can be easily performed via internet

Professional software RIP for multi colour separation TxLink 3 Lite
txlink3-lite mimaki

  • Spot colour can be assigned to each colour on separation plates
  • ICC profi le creation from CMYK + spot colours
  • Colour replacement on raster data
  • A variety of panelling functions, including step-and-repeat layout, which are useful for textile designing

All TS300P-1800 inks are ECO PASSPORT by OEKO-TEX® certified.
