CJV300 Series

High-speed, integrated printer/cutter

Mimaki’s latest integrated printer/cutter delivers new levels of creativity with versatile and vibrant ink types, including new Silver, Orange and Light Black. CJV300 Series achieves the highest print speeds in its class, with innovative technologies ensuring unrivalled output quality for signmakers, display graphics professionals and printshops.

High print speeds
Up to 10 colour options
Low running costs
  • Fast printing speeds up to 105.9m2 per hour
  • High quality print resolution of up to 1,440dpi
  • Two different printing widths: 1,361mm and 1,610mm
  • Choice of multiple solvent ink sets, including:
    10-colour options (SS21) including; Silver, Orange, Light Black & White inks
  • Nozzle Check Unit (NCU) and Nozzle Recovery System (NRS) ensure continuous print operations
  • UISS and optional MBIS III on board 2 litre bulk ink system
  • 3-way intelligent heater

Create…

Metallic Stickers, Decals, Die-cut Labels, Signage, Vehicle Graphics, Banners, Posters, PoS,
Backlit and Exhibition Graphics, Garment Marking, Canvas Prints and much more…

Specifications of CJV300 Series


Print head On-demand piezo head (staggered dual-head)
Resolution 360 dpi, 540 dpi, 720 dpi, 1,080dpi, 1,440 dpi
Ink Type/Colour Eco-solvent ink
SS21 (C, M, Y, K, Lc, Lm, Lk, Or, W, Si)
BS3 (C, M, Y, K)
BS4 (C, M, Y, K)
ES3 (C, M, Y, K, Lc, Lm)
Water-based sublimation ink
Sb53 (Bl, M, Y, K, DK, Lbl, Lm)
Sb54 (BLT, MT, YT, KT)
Ink Package size SS21: 440ml cartridge/2L Ink pack*2 (W, Si 220ml cartridge only)
ES3: 440ml cartridge
BS3: 600ml Ink pack/2L Ink pack*2
BS4: 600ml Ink pack/2L Ink pack*2
Sb53: 440ml Ink cartridge/2L Ink pack*2
Sb54: 440ml Ink cartridge/2L Ink pack*2
Max. printing width CJV300-130: Max.1,361mm
CJV300-160: Max.1,610mm
Max. media width CJV300-130: Max.1,371mm
CJV300-160: Max.1,620mm
Media thickness 1.0mm or less
Roll weight 40kg or less
Outside dimension CJV300-130: 2,525mm(W) x 700mm(D) x 1,392mm(H)
CJV300-160: 2,775mm(W) x 700mm(D) x 1,392mm(H)
Body weight CJV300-130: 167kg
CJV300-160: 178kg
Power supply 2x Single phase (AC100~120V/220~240V +/-10%˙) 50/60Hz±1Hz
Power consumption 1,440Wx2 or less (100V) / 1,920Wx2 or less (200V)
Applicable standards VCCI class A / FCC class A / CE Marking (EMC, Low Voltage Machinery) / CB report / UL60950-1ETL / RoHS / REACH / CCC (pending) / Energy Star / RCM
Operational environment Temperature: 20–30 °C (68–86 °F) Humidity: 35–65% Rh (Non condensing)




CJV300 Series inks Sb53 & Sb54 are ECO PASSPORT by OEKO-TEX® certified.



Features of CJV300 Series

High print Speeds

print-speed cjv300

print-speed cjv300


Uninterrupted Ink Supply System (UISS)

Uninterrupted Ink Supply System
Utilises two cartridges per colour in 4-colour mode. When one cartridge runs out of ink the system switches automatically to the second cartridge of the same colour, enabling long unattended printing.


3-Way intelligent heater

intelligent-heater
A 3-way intelligent heater fixes droplets placed on media. By using Mimaki’s original technology in heating the media at a controlled temperature, ink can be fixed while maintaining high colour development and high image quality. Thus the CJV300 provides both steady colour development and easy handling after printing.

  • Pre-heater: Heats media to the optimum temperature
    before printing.
  • Print heater: Dries ink after it lands on media before it
    bleeds, improving colour development.
  • Post-heater: Enhances ink drying and achieves
    stable take-up.
  • Top blower: Air blower supports drying of ink.

MAPS3 (Mimaki Advanced Pass System 3)

maps3
Reduces banding by dispersing ink drops between passes.




Waveform Control Technology

waveform-control-technology
Ensures high quality print resolution, by jetting ink drops in straight lines with almost perfect round dots, delivering clear and sharp letters, lines and edges.





Large ink dot size in high speed mode

Delivers high density print by removing the gap between dots.

large-ink-dot-size










Silver Ink (For brilliant metallic effects)

Newly developed SS21 silver ink is available. Being 1.67* times brighter than conventional silver inks, SS21 ink adds brilliant and beautiful mirror effects to print results.
*Obtained from comparison measurements of SS21 and ES3 silver inks conducted at the Mimaki HQ

silver-ink


Orange Ink (Faithful colour reproduction)

By using the orange ink as a process colour, 94.8% of the PANTONE colour chart is covered with approximate colours. Thanks to a wider gamut with the orange ink, food freshness can be simulated, and corporate colours can be faithfully represented.

orange-ink


Light Black Ink (greater definition)

The light black ink improves the printed grayscale gradation. It also faithfully represents monochrome data without introducing unexpected colour shifts. Light black ink ensures a more accurate colour representation.

light-black-ink


Productivity maintenance

Productivity-maintenance
(NRS*1)

The NRS substitutes defective nozzles with non-defective nozzles until the technician arrives.
This feature enables uninterrupted print operations and continuous productivity.

*1 NRS: Nozzle Recovery System *2 10 nozzles per nozzle row can be registered.




Prevention, print quality problems

Prevention,-print-quality-problems
(NCU*)
1 NRS: Nozzle Recovery System *2 10 nozzles per nozzle row can be registered.
The CJV300 is equipped with Mimaki’s original automatic NCU. Clogged nozzles are automatically detected and cleaned by the NCU. If the clogging is not resolved by cleaning, the CJV300 automatically sets the nozzle recovery function NRS and resumes printing. These functions significantly reduce the waste printing caused by clogged nozzles during a continuous printing run.

* NCU: Nozzle Check Unit


Stable printing using the ink circulation system – MCT*

stable-printing
MCT is a standard feature included to effectively avoid the settling of white and silver pigments in the ink lines by regularly circulating the ink. It prevents print troubles and enables stable output from the start of operation. In addition, MCT contributes to reduction of ink waste, thereby supporting environmentally and economically friendly applications.






rasterlink6

Sophisticated RIP Software maximizes performance

Intuitive and user-friendly operation

3-layer printing
Enables simultaneous 3-layer printing: e.g. Colour White Colour

Web update function is supported:
This facility enables easy program updates and profile downloading to be performed via the internet.

rasterlink6
1. Easy to follow icons enable intuitive and user-friendly operation

rasterlink6
2. Related settings feature in one window to simplify RIP operations with ‘Register as Favourite’ option available for regularly used layouts

rasterlink6
3. Printing progress can be monitored on the main screen





CJV300 Series inks Sb53 & Sb54 are ECO PASSPORT by OEKO-TEX® certified.
