UJV-160 Hybrid UV LED Inkjet Printer
The UJV-160 offers extraordinary flexibility. With the environmentally-friendly UV LED technology, it offers problem-free printing on heat sensitive media. Moreover, users can choose between roll and rigid media, as well as either hard or flexible UV inks. No matter what the choice is, UJV-160 opens up endless possibilities to print on different kinds of substrates and for various applications.
The UJV-160 delivers •••
- No drying time, the printed media is cured immediately
- No media deformation
- Flexible UV inks stretch, which is ideal for vehicle wrapping
- Most environmentally-friendly solution for large format printing
- Includes tables for printing onto rigid materials up to 10 mm thickness
- Ideal print and cut solution with the CF2 series flatbed cutting plotter
Applications of UJV-160
Roll : Vinyl, banner, paper, canvas, transparent PET film, and more.
Rigid : Acrylic, aluminium composite board, styrene board, corrugated card board, pasteboard, and more.
Roll: backlit signs, floor graphics, vehicle wrapping, posters, banners, indoor graphics, etc.
Rigid: signboards for POS displays, pen holder, large panel, etc.
Specifications of UJV-160
|Print head||On-demand piezo head|
|Maximum print width||Roll: 161 cm, Rigid: 160 cm|
|Printing resolutions||600, 1200 dpi|
|Ink type||UV-curable ink (flexible and hard inks available)
5 colours: C / M / Y / K / W
|Ink capacity||1,200 ml (600 ml x 2 cartridge) per colour|
|Media Size||162 cm|
|Media weight||Roll: max. 25 kg
Rigid: max. 12 kg
|Roll inside diameter||2 or 3 inch|
|Media heater||Pre / print heater|
|Dimensions (w x d x h)||Main unit: 330 cm x 78 cm x 129 cm
With table: 330 cm x 430 cm x 129 cm
|Weight||Main unit: 260 kg
Media table: 50 kg x 2 units
Features of UJV-160
The Mimaki UJV-160 comes with feed and delivery tables for printing on rigid substrates, in addition to printing roll-to-roll. You can print on rigid substrates of up to 10 mm thickness and 12 kg weight. The tables are foldable, thereby saving space when not needed.
UV LED Curing Technology
The UJV-160 employs UV LED printing technology, which does not generate excessive heat, allowing the machine to print directly on a wide range of substrates, including heat-sensitive materials, without any media deformation.
No drying time, immediately ready for post-processing
Aqueous or solvent inks require post printing drying. This is eliminated using UV technology and consequently, the media is ready for laminating immediately after printing. The job turnaround time from printing to processing is shortened and improves work efficiency and productivity.
Three Types of UV Curable Ink
Three types of ink are available for the UJV-160. LH-100 hard UV ink excels in scratch and chemical resistance as well as in colour reproduction; LF-200 flexible UV ink enables stretching of ink up to 200% during post-processing work; LF-140 offers strong gradation in 6-colour printing and is more flexible than LH-100 ink.
A. 4/6 colours only
Without white ink as a basis for overprinting, the colours are not as vivid as they should be.
B 4/6 colours + white
With the white ink overlay print, the images are bright and vivid.
Media warranty programs
The UJV-160 can be supported by warranty programs of 3M and Avery Graphics when printing with LF-200 inks. Warranty (periods) can vary based on region, type of application, type of media and graphic protection. Please contact 3M or Avery in your country for further information.
Ideal print and cut solution with CF2 Series
For printing and cutting of light weight sign boards UJV-160 and CF2 Series is an ideal print and cut solution, especially in terms of cost-performance relation, since CF2 Series is a
reliable high quality flatbed cutter that comes at a very competitive price.
Standard included RIP software
The high performance RIP software is designed to fully enable all advanced features of the UJV-160 printer. 16 bit rendering eliminates tone jump and produces fine colour reproductions.
- UV LEDs have longer life and consume less energy than conventional UV lamps
- Less transfer waste and no wasted inventory by printing on-demand, direct-to-substrate
- No noticeable odour
