CJV30 Series
Mimaki CJV30 Series: Integrated Inkjet Printer / Cutters (Print and Cut)
Mimaki has further expanded its award winning sign and graphics systems with the CJV30 Series of unique integrated print and cut solutions – with 4 print widths available, providing even greater flexibility for end-users from retailers and copy shops to professional signmakers and print service providers.
Mimaki CJV30 series delivers •••
- 4 different print widths (60 / 100 / 130 / 160 cm)
- High quality printing up to 1440 dpi
- Maximum printing speed 17.5 m2/h
- Automatic switching from printing to cutting
- Continuous crop mark detection for accurate contour cutting
- Simultaneous white and full colour printing
- Sparkling Metallic ink
- Continuous printing with the Uninterrupted Ink Supply System
- RIP, cutting, and creation software included
CJV30 BS Series: High performance print and cut solution
Mimaki CJV30 BS series delivers •••
The CJV30 BS is specifically available to non-European Union countries
- Very affordable BS2 ink
- BS2 ink is available in 600 ml replaceable ink packs.
- high drying capacity and minimal ink bleeding
Applications
Applications of CJV Series
CJV30-60
High quality seals, labels, stickers, A1 posters, promotional prints, and point of purchase displays, transfers for T-shirts and more.
CJV30-100
A0/A1 posters, POP displays, high quality stickers, labels, seals, transfers for T-shirts and more.
CJV30-130 / CJV30-160
Large sized signs, such as large posters, vehicle graphics, POP displays, backlit, window decoration, floor signage and more.
Substrates
Vinyl, banner, canvas, (blueback) paper, solvent transfer paper, and more
Specifications
Specifications of CJV30 Series
| Maximum print/cut width | CJV30-60 : 61 cm CJV30-100 : 102 cm CJV30-130 : 136.1 cm CJV30-160 : 161 cm |
| Printing resolutions | 540, 720, 1440 dpi |
| Ink type | Solvent ink: SS21, ES3 ink CJV30 BS: BS2 Ink |
| Ink capacity | 4-colour mode: 440 cc x 2 = 880 cc per colour 6-colour mode: 440 cc x 1 = 440 cc per colour CJV30 BS: 4-colour mode: 600 cc x 2 = 1200 cc per colour |
| Media Size | CJV30-60 : 62 cm CJV30-100 : 103 cm CJV30-130 : 137.1 cm CJV30-160 : 162 cm |
| Roll weight | Less than 25 kg |
| Roll inside diameter | 2 or 3 inch |
| Maximum cutting speed | 30 cm/s |
| Media heater | Pre/print/post heater |
| Interface | USB 2.0 |
| Power | AC100V-240V, less than 1380 VA |
| Dimensions (w x d x h) | CJV30-60 : 152.4 cm x 73.9 cm x 142.4 cm CJV30-100 : 193.4 cm x 73.9 cm x 142.4 cm CJV30-130 : 228.9 cm x 73.9 cm x 142.4 cm CJV30-160 : 253.8 cm x 73.9 cm x 142.4 cm |
| Weight | CJV30-60 : 110 kg CJV30-100 : 130 kg CJV30-130 : 145 kg CJV30-160 : 160 kg |
Features
Features of CJV30 Series
High speed and high quality
Mimaki’s CJV30 series comes in 4 different print widths and is capable of printing up to 17.5 sqm/h (540 x 720 dpi, 4 colours). In standard mode CJV30 can print 11.9 sqm/h (540 x 1080 dpi, 4 colours). The symmetrical ink cartridge arrangement enables reliable and detailed high quality image generation even with bidirectional printing.
CJV30 can print up to 1440 dpi with three different dot sizes. With Mimaki’s unique white ink overlay feature, even more vivid images can be realised. More brilliant colour is made possible, especially when printing on transparent media.
Automatic switching from printing to cutting
The number of pinch rollers and their clamp pressures can be set from the RIP software and the pinch roller pressure is automatically changed to suit the thickness of the media. By raising the pinch rollers in the middle at the time of cutting, peeling-off media after cutting is eliminated.
This full automatic function enables unattended operation without manual intervention from the start of printing to the end of cutting. CJV30 automatically adjusts to ensure accurate media feed.
Advanced Cutting Functions
Accurate contour cutting
For accurate contour cutting of printed images, the continuous crop mark detection recognises registration marks that are printed on the media. Even with a laminated print, contour cutting is performed with great accuracy.
Mimaki’s Half-Cut function
This function creates a series of half and die cuts leaving a few minimal connection points preventing the image from falling out when printing stickers etc.
Two solvent inks available
SS21 solvent ink
SS21 fast drying solvent ink enables immediate cutting after printing and eliminates peeling when cut. Mimaki’s innovative SS21 white ink is available for printing on transparent and coloured substrates, such as window decoration.
ES3 eco-solvent ink
Virtually odourless and user-friendly ink that does not require any special ventilation. Available in white and silver ink for producing more vivid colours and creating stunning metallic effects.
CJV30BS: BS2 Solvent ink
Not only is BS2 ink very affordable, but it also achieves high drying capacity and minimal ink bleeding. Other benefi ts include high scratch resistance and a wide colour gamut. Additionally, BS2 ink users enjoy one-year Mimaki warranty,
which includes print heads. BS2 ink is available in 600 ml replaceable ink packs.
Uninterrupted Ink Supply System (UISS)
The unique Uninterrupted Ink Supply System (UISS) automatically switches to another cartridge when supply runs out, allowing overnight continuous operation. Ink cartridges can also be replaced during operation.
When one ink cartridge runs out of ink, the indicator will light up red, while the system switches automatically to the second cartridge of the same colour.
Easy-to-use Standard Software
Three different software packages are included as standard. From RIP to cutting, the software answers all professional requirements for multiple applications. In addition, easy to operate software for preparing the print and cut data is enclosed.
Brochure
Brochure of CJV30 Series
Please find the Mimaki CJV30 Series brochure below. Click the image to see the brochure.
